EDM Material - Silicon Carbide Machining
Calix Ceramic Solutions offers a low resistivity sintered silicon carbide (SiC) that is an Electrical Discharge Machineable (EDM) material. The material's high density and uniform low electrical resistivity allow it to be a successful EDM material.
Allow Calix Ceramic Solutions' Application Engineers to work hand in hand with your engineering team to find the correct material solution for your application.
Low Resistivity Silicon Carbide Properties
| Physical Property | Units | Typical Value |
| Composition | - | SiC |
| Grain Size | µm | 4-10 |
| Density | g/cc | 2.90-2.96 |
| Hardness (Vickers) | GPa | 15 |
| Young's Modulus | GPa | 256-296 |
| Coefficient of Thermal Expansion 20-700°C | ppm/K | 4.1 |
| Thermal Conductivity | W /m-K | 140 |
| Electrical Resitivity (Four terminal) | Ω-cm | 10^-2 |
All properties are at room temperature (20°C) unless otherwise stated.
